Module MAPLEAF.Rocket.rocket
Rocket ties together the code in MAPLEAF.GNC, MAPLEAF.Rocket, MAPLEAF.Motion, and MAPLEAF.ENV` to
simulate the flight of a single rocket or dropped rocket stage (Rocket always only represents a single rigid body at a time).
New instances of Rocket are created by Simulation to represent dropped stages.
Expand source code
"""
`Rocket ties together the code in `MAPLEAF.GNC`, `MAPLEAF.Rocket`, `MAPLEAF.Motion`, and `MAPLEAF.ENV` to
simulate the flight of a single rocket or dropped rocket stage (`Rocket` always only represents a single rigid body at a time).
New instances of `Rocket` are created by `MAPLEAF.SimulationRunners.Simulation` to represent dropped stages.
.. image:: https://media.defense.gov/2020/Apr/01/2002273784/780/780/0/200326-F-KD758-1012.JPG
"""
import math
import os
import matplotlib.pyplot as plt
from MAPLEAF.ENV import Environment, EnvironmentalConditions
from MAPLEAF.GNC import RocketControlSystem
from MAPLEAF.IO import Log, Logging, SubDictReader, TimeStepLog
from MAPLEAF.IO.HIL import HILInterface
from MAPLEAF.Motion import (AeroParameters, AngularVelocity, Inertia,
Quaternion, RigidBody, RigidBody_3DoF,
RigidBodyState, RigidBodyState_3DoF,
StatefulRigidBody, Vector)
from MAPLEAF.Rocket import (AeroFunctions, BoatTail, BodyComponent,
PlanarInterface, SimEventDetector, Stage,
initializeForceLogging)
from MAPLEAF.Rocket.CompositeObject import CompositeObject
__all__ = [ "Rocket" ]
class Rocket(CompositeObject):
'''
Class used to represent a single flying rigid body composed of `MAPLEAF.Rocket.Stage` objects.
New instances of this class are also created to model the flight of dropped stages.
'''
#### Initialization ####
def __init__(self, rocketDictReader, silent=False, stageToInitialize=None, simRunner=None, environment=None):
'''
Initialization of Rocket(s) is most easily completed through an instance of Simulation
To get a single Rocket object, initialize a Simulation and call `MAPLEAF.SimulationRunners.Simulation.createRocket()`.
This will return a Rocket initialized on the pad with all its stages, ready for flight.
If initializing manually, can either provide fileName or simDefinition. If a simDefinition is provided, it will be used and fileName will be ignored.
Inputs:
* rocketDictReader: (`MAPLEAF.IO.SubDictReader`) SubDictReader pointed at the "Rocket" dictionary of the desired simulation definition file.
* silent: (bool) controls console output
* stageToInitialize: (int or None) controls whether to initialize a complete Rocket or a single (usually dropped) stage. None = initialize complete rocket. n = initialize only stage n, where n >= 1.
* simRunner: (`MAPLEAF.SimulationRunners.Simulation`) reference to the current simulation driver/runner
* environment: (`MAPLEAF.ENV.Environment`) environment model from which the rocket will retrieve atmospheric properties and wind speeds
'''
self.rocketDictReader = rocketDictReader
self.simDefinition = rocketDictReader.simDefinition
self.simRunner = simRunner
''' Parent instance of `MAPLEAF.SimulationRunners.Simulation` (or derivative sim runner). This is usually the object that has created the current instance of Rocket. '''
self.environment = environment
''' Instance of `MAPLEAF.ENV.Environment` '''
if self.environment == None:
# If no environment is passed in, create one
self.environment = Environment(self.simDefinition, silent=silent)
self.name = rocketDictReader.getString("name")
self.silent = silent
''' Controls output to console '''
self.stage = stageToInitialize
''' If controls whether the whole rocket is initialized (if == None), or a single stage is initialized (Integer stage number) '''
self.stages = []
'''
A list of `MAPLEAF.Rocket.Stage` objects that make up the rocket, ordered from top to bottom.
Populated by `_initializeStages`.
'''
self.recoverySystem = None
'''
Reference to the current Rocket's (which can represent a dropped stage) recovery system. Only a single recovery system is allowed per stage.
Set in `MAPLEAF.Rocket.RecoverySystem.__init__`
'''
self.rigidBody = None
'''
(`MAPLEAF.Motion.RigidBody` or `MAPLEAF.Motion.RigidBody_3DoF`) Responsible for motion integration.
Set in `_initializeRigidBody()`.
'''
self.isUnderChute = False
''' (bool) Controlled by `MAPLEAF.Rocket.Recovery.RecoverySystem._deployNextStage()` '''
self.mainChuteDeployTime = None
''' (float) Filled in during flight by `MAPLEAF.Rocket.Recovery.RecoverySystem._deployNextStage()` '''
self.engineShutOffTime = None
''' (float) Filled in by `MAPLEAF.Rocket.Propulsion.TabulatedMotor.__init__()` upon initialization '''
self.turbulenceOffWhenUnderChute = rocketDictReader.getBool("Environment.turbulenceOffWhenUnderChute")
''' (bool) '''
self.maxDiameter = self._getMaxBodyTubeDiameter()
''' (float) Holds maximum constant-size body tube diameter, from bodytube components in stages '''
self.Aref = math.pi * self.maxDiameter**2 / 4
'''
Reference area for force and moment coefficients.
Maximum rocket cross-sectional area. Remains constant during flight to retain a 1:1 relationship b/w coefficients in different parts of flight.
Always based on the maximum body tube diameter in the fully-assembled rocket.
'''
# TODO: Remove
self.targetLocation = None
self.simEventDetector = SimEventDetector(self)
''' (`MAPLEAF.Rocket.SimEventDetector`) Used to trigger things like recovery systems and staging '''
self.eventTimeStep = rocketDictReader.getFloat("SimControl.TimeStepAdaptation.eventTimingAccuracy")
''' If using an adaptive time stepping method, the time step will be overridden near non-time-deterministic discrete events, possibly all the way down to this minimum value '''
self.addZeroLengthBoatTailsToAccountForBaseDrag = rocketDictReader.getBool("Aero.addZeroLengthBoatTailsToAccountForBaseDrag")
''' Controls whether zero-length boat tails are automatically added to the bottom of rockets without them, to make sure base drag is accounted for '''
self.fullyTurbulentBL = rocketDictReader.getBool("Aero.fullyTurbulentBL")
''' Controls whether skin friction is solved assuming a fully turbulent BL or using laminar/transitional flow at lower Reynolds numbers '''
self.surfaceRoughness = rocketDictReader.getFloat("Aero.surfaceRoughness")
''' Default surface roughness for all rocket components '''
self.finenessRatio = None
''' Used in some aerodynamic functions. Updated after initializing subcomponents, and throughout the flight. None if no BodyComponent(s) are present in the rocket '''
self.engineShutOff = False
'''Used to shut off engines in MAPLEAF.Rocket.Propulsion.DefinedMotor class. Currently set in MAPLE_AF.GNC.Navigation'''
#### Init Hardware in the loop ####
subDicts = rocketDictReader.getImmediateSubDicts()
if "Rocket.HIL" in subDicts:
self.hardwareInTheLoopControl = "yes"
quatUpdateRate = rocketDictReader.getInt("HIL.quatUpdateRate")
posUpdateRate = rocketDictReader.getInt("HIL.posUpdateRate")
velUpdateRate = rocketDictReader.getInt("HIL.velUpdateRate")
teensyComPort = rocketDictReader.getString("HIL.teensyComPort")
imuComPort = rocketDictReader.getString("HIL.imuComPort")
teensyBaudrate = rocketDictReader.getInt("HIL.teensyBaudrate")
imuBaudrate = rocketDictReader.getInt("HIL.imuBaudrate")
self.hilInterface = HILInterface(quatUpdateRate,posUpdateRate,velUpdateRate, teensyComPort, imuComPort, teensyBaudrate, imuBaudrate)
else:
self.hardwareInTheLoopControl = "no"
#### Initialize Logging ####
self.timeStepLog = None
''' Log containing one entry per time step, logs rocket state. None if logging level == 0 '''
self.derivativeEvaluationLog = None
''' Log containing one entry per rocket motion derivative evaluation, contains component forces. None if logging level < 2 '''
loggingLevel = int(self.simDefinition.getValue("SimControl.loggingLevel"))
self.loggingLevel = loggingLevel
if loggingLevel > 0:
# Create the time step log and add columns to track the rocket state between each time step
self.timeStepLog = TimeStepLog()
zeroVector = Vector(0,0,0)
self.timeStepLog.addColumn("Position(m)", zeroVector)
self.timeStepLog.addColumn("Velocity(m/s)", zeroVector)
self.timeStepLog.addColumn("OrientationQuaternion", Quaternion(0,0,0,0))
self.timeStepLog.addColumn("EulerAngle(rad)", zeroVector)
self.timeStepLog.addColumn("AngularVelocity(rad/s)", zeroVector)
if "Adapt" in self.simDefinition.getValue("SimControl.timeDiscretization"):
self.timeStepLog.addColumn("EstimatedIntegrationError", 0)
if loggingLevel > 1:
self.derivativeEvaluationLog = Log()
zeroVector = Vector(0,0,0)
self.derivativeEvaluationLog.addColumn("Position(m)", zeroVector)
self.derivativeEvaluationLog.addColumn("Velocity(m/s)", zeroVector)
self.derivativeEvaluationLog.addColumn("OrientationQuaternion", Quaternion(0,0,0,0))
self.derivativeEvaluationLog.addColumn("AngularVelocity(rad/s)", zeroVector)
self.derivativeEvaluationLog.addColumn("CG(m)", zeroVector)
self.derivativeEvaluationLog.addColumn("MOI(kg*m^2)", zeroVector)
self.derivativeEvaluationLog.addColumn("Mass(kg)", 0)
self.derivativeEvaluationLog.addColumn("Wind(m/s)", zeroVector)
self.derivativeEvaluationLog.addColumn("AirDensity(kg/m^3)", 0)
self.derivativeEvaluationLog.addColumn("Mach", 0)
self.derivativeEvaluationLog.addColumn("UnitRe", 0)
self.derivativeEvaluationLog.addColumn("AOA(deg)", 0)
self.derivativeEvaluationLog.addColumn("RollAngle(deg)", 0)
self.derivativeEvaluationLog.addColumn("CPZ(m)", 0)
self.derivativeEvaluationLog.addColumn("AeroF(N)", zeroVector)
self.derivativeEvaluationLog.addColumn("AeroM(Nm)", zeroVector)
self.derivativeEvaluationLog.addColumn("GravityF(N)", zeroVector)
self.derivativeEvaluationLog.addColumn("TotalF(N)", zeroVector)
#### Init Components ####
self._createStages()
self._initializeRigidBody()
self._switchToStatefulRigidBodyIfRequired()
self._sortStagesAndComponents()
self._initializeStagingTriggers()
self._precomputeComponentProperties()
#### Init Parent classes ####
CompositeObject.__init__(self, self.stages)
self._updateFinenessRatio()
# Adjust rigid body state position to correspond to the rocket's CG instead of nose cone tip position
self._moveStatePositionToCG()
#### Init Guidance/Navigation/Control System (if required) ####
self.controlSystem = None
''' None for uncontrolled rockets. `MAPLEAF.GNC.ControlSystems.RocketControlSystem` for controlled rockets '''
if ( rocketDictReader.tryGetString("ControlSystem.controlledSystem") != None or rocketDictReader.tryGetString("ControlSystem.MomentController.Type") == "IdealMomentController") and stageToInitialize == None:
# Only create a control system if this is NOT a dropped stage
ControlSystemDictReader = SubDictReader("Rocket.ControlSystem", simDefinition=self.simDefinition)
controlSystemLogging = loggingLevel > 3
self.controlSystem = RocketControlSystem(ControlSystemDictReader, self, log=controlSystemLogging, silent=silent)
def _getMaxBodyTubeDiameter(self):
''' Gets max body tube diameter directly from config file '''
stageDicts = self._getStageSubDicts()
maxDiameter = 0
for stageDict in stageDicts:
componentDicts = self.rocketDictReader.getImmediateSubDicts(stageDict)
for componentDict in componentDicts:
className = self.rocketDictReader.getString(componentDict + ".class")
if className == "Bodytube":
diameter = self.rocketDictReader.getFloat(componentDict + ".outerDiameter")
maxDiameter = max(maxDiameter, diameter)
return maxDiameter
def _getStageSubDicts(self):
# Get all immediate subdictionaries of 'Rocket'
stageDicts = self.rocketDictReader.getImmediateSubDicts()
# Assume all subdictionaries represent rocket stages except for these exceptions
nonStageSubDicts = [ "Rocket.ControlSystem", "Rocket.HIL", "Rocket.Aero" ]
# Remove them from the list if they're in it
for dictName in nonStageSubDicts:
if dictName in stageDicts:
stageDicts.remove(dictName)
return stageDicts
def _initializeRigidBody(self):
#### Get initial kinematic state (in launch tower frame) ####
initPos = self.rocketDictReader.getVector("position")
initVel = self.rocketDictReader.getVector("velocity")
# Check whether precise initial orientation has been specified
rotationAxis = self.rocketDictReader.tryGetVector("rotationAxis", defaultValue=None)
if rotationAxis != None:
rotationAngle = math.radians(self.rocketDictReader.getFloat("rotationAngle"))
initOrientation = Quaternion(rotationAxis, rotationAngle)
else:
# Calculate initial orientation quaternion in launch tower frame
initialDirection = self.rocketDictReader.getVector("initialDirection").normalize()
angleFromVertical = Vector(0,0,1).angle(initialDirection)
rotationAxis = Vector(0,0,1).crossProduct(initialDirection)
initOrientation = Quaternion(rotationAxis, angleFromVertical)
initAngVel = AngularVelocity(rotationVector=self.rocketDictReader.getVector("angularVelocity"))
initState_launchTowerFrame = RigidBodyState(initPos, initVel, initOrientation, initAngVel)
# Convert to the global inertial frame
initState_globalInertialFrame = self.environment.convertInitialStateToGlobalFrame(initState_launchTowerFrame)
# Get desired time discretization method
timeDisc = self.rocketDictReader.getString("SimControl.timeDiscretization")
#TODO: Check for additional parameters to integrate - if they exist create a StatefulRigidBody + RocketState instead!
# Ask each rocket component whether it would like to add parameters to integrate after all the components have been initialized
discardDtCallback = None if (self.simRunner == None) else self.simRunner.discardForceLogsForPreviousTimeStep
#### Initialize the rigid body ####
self.rigidBody = RigidBody(
initState_globalInertialFrame,
self._getAppliedForce,
self.getInertia,
integrationMethod=timeDisc,
discardedTimeStepCallback=discardDtCallback,
simDefinition=self.simDefinition
)
def _createStages(self):
''' Initialize each of the stages and all of their subcomponents. '''
stageDicts = self._getStageSubDicts()
# If we're initializing a dropped stage, figure out which one
if self.stage != None:
stageNumbers = []
stageNumberSet = set()
for stageDict in stageDicts:
stageNumber = self.rocketDictReader.getFloat(stageDict + ".stageNumber")
stageNumbers.append(stageNumber)
stageNumberSet.add(stageNumber)
if len(stageNumbers) != len(stageNumberSet):
raise ValueError("For multi-stage rockets, each stage must have a unique stage number. Set the Rocket.StageName.stageNumber value for each stage. 0 for first stage, 1 for second, etc...")
stageNumbers.sort()
stageToInitialize = stageNumbers[self.stage]
# Initialize Stage(s)
initializingAllStages = (self.stage == None)
for stageDictionary in stageDicts:
stageDictReader = SubDictReader(stageDictionary, self.simDefinition)
stageNumber = stageDictReader.getFloat("stageNumber")
if initializingAllStages or stageNumber == stageToInitialize:
newStage = Stage(stageDictReader, self)
self.stages.append(newStage)
if newStage.name not in self.__dict__: # Avoid clobbering existing info
setattr(self, newStage.name, newStage) # Make stage available as rocket.stageName
def _sortStagesAndComponents(self):
# Create Planar Interfaces b/w components inside stages
for stage in self.stages:
stage.components = PlanarInterface.sortByZLocation(stage.components, self.rigidBody.state)
stage.componentInterfaces = PlanarInterface.createPlanarComponentInterfaces(stage.components)
# Create planar interfaces b/w stages
self.stages = PlanarInterface.sortByZLocation(self.stages, self.rigidBody.state)
self.stageInterfaces = PlanarInterface.createPlanarComponentInterfaces(self.stages)
if self.maxDiameter > 0:
# Only run this if we're running a real rocket with body tubes
self._ensureBaseDragIsAccountedFor()
def _initializeStagingTriggers(self):
''' Set up trigger conditions for staging '''
# Self.stage is not passed in if the current instance represents a rocket ready to launch - then we have to set up staging events
if self.stage == None:
for stageIndex in range(len(self.stages)):
stage = self.stages[stageIndex]
if stage.separationConditionType != 'None':
self.simEventDetector.subscribeToEvent(
stage.separationConditionType,
self._stageSeparation,
stage.separationConditionValue,
triggerDelay=stage.separationDelay
)
if stageIndex != len(self.stages)-1:
# Set all upper stage motors to ignite a very long time in the future
stage.motor.updateIgnitionTime(1000000000, fakeValue=True)
else:
# Otherwise this rocket object is representing a single dropped stage, and no stage separations are necessary
# Motor is burned out
self.stages[0].motor.updateIgnitionTime(-1000000000, fakeValue=True)
def _switchToStatefulRigidBodyIfRequired(self):
'''
Query all of the rocket components to see if any of them are stateful by attempting to call their getExtraParametersToIntegrate function
If the rocket contains stateful components, the rocket state is converted to a StateList and all of these state variables requested by components are added to it
Otherwise, nothing changes and the rocket state remains a RigidBodyState
'''
varNames = []
initVals = []
derivativeFuncs = []
# Query all of the components
for stage in self.stages:
for component in stage.components:
try:
paramNames, initValues, derivativeFunctions = component.getExtraParametersToIntegrate()
varNames += paramNames
initVals += initValues
derivativeFuncs += derivativeFunctions
except AttributeError:
pass # No extra parameters to integrate
# If any of the components are stateful, keep track of their states in the main rocket state
if len(varNames) > 0:
if len(varNames) != len(initVals) or len(initVals) != len(derivativeFuncs):
raise ValueError("ERROR: Mismatch in number of extra parameters names ({}), init values({}), and derivative functions({}) to integrate".format(len(varNames), len(initVals), len(derivativeFuncs)))
# Switch to a stateful rigid body
initState = self.rigidBody.state
forceFunc = self.rigidBody.forceFunc
inertiaFunc = self.rigidBody.inertiaFunc
integrationMethod = self.rocketDictReader.getString("SimControl.timeDiscretization")
discardDtCallback = None if (self.simRunner == None) else self.simRunner.discardForceLogsForPreviousTimeStep
self.rigidBody = StatefulRigidBody(
initState,
forceFunc,
inertiaFunc,
integrationMethod=integrationMethod,
discardedTimeStepCallback=discardDtCallback,
simDefinition=self.simDefinition
)
# Add the additional state variables
for i in range(len(varNames)):
self.rigidBody.addStateVariable(varNames[i], initVals[i], derivativeFuncs[i])
def _precomputeComponentProperties(self):
for stage in self.stages:
for component in stage.components:
try:
component.precomputeProperties()
except AttributeError:
pass
def _moveStatePositionToCG(self):
''' Moves self.rigidBody.state.position to have it represent the rocket's initial CG position, not the initial nose cone position '''
initInertia = self.getInertia(0, self.rigidBody.state)
CGPosition_wrtNoseCone_localFrame = initInertia.CG
CGPosition__wrtNoseCone_globalFrame = self.rigidBody.state.orientation.rotate(CGPosition_wrtNoseCone_localFrame)
CGPosition_globalFrame = self.rigidBody.state.position + CGPosition__wrtNoseCone_globalFrame
self.rigidBody.state.position = CGPosition_globalFrame
def getLength(self):
totalLength = 0
for stage in self.stages:
try:
totalLength += stage.getLength()
except TypeError:
pass # Stage Length was None - no body components in stage
return totalLength
def plotShape(self):
plt.figure()
plt.gca().set_aspect('equal')
rocketInertia = self.getInertia(0, self.rigidBody.state)
TotalCG = rocketInertia.CG.Z
TotalMass = rocketInertia.mass
TotalCGplt = plt.plot(TotalCG, 0, color='b', marker='d', label='Total CG', linestyle='None')
CGsubZ = []
CGsubY = []
plt.title('Total Rocket CG: %10.4f m \n Total Rocket Mass: %10.4f Kg' % (TotalCG,TotalMass) )
for stage in self.stages:
zCGs, yCGs = stage.plotShape()
# Add subcomponents CGs to arrays
CGsubZ += zCGs
CGsubY += yCGs
SubCGplt = plt.plot(CGsubZ, CGsubY, color='g', marker='.', label='Subcomponent CG', linestyle='None')
legendHeight = self.maxDiameter
plt.legend(loc='upper center', bbox_to_anchor = (0.5,-1.05))
plt.show()
#### Stage Separation ####
def _stageSeparation(self):
print("Stage {} Separation".format(self.simRunner.stagingIndex + 1))
# Initialize dropped stage as a new rocket
self.simRunner.createNewDetachedStage()
# Drop stage from current rocket
self._dropStage()
# Ignite next motor (set ignition time to the time of stage separation)
currentTime = self.rigidBody.time
self.stages[0].motor.updateIgnitionTime(currentTime)
self._ensureBaseDragIsAccountedFor()
self._updateFinenessRatio()
def _dropStage(self, stageIndex=-1):
droppedStage = self.stages.pop(stageIndex)
delattr(self, droppedStage.name)
self.recomputeFixedMassInertia()
if self.controlSystem != None:
# Check whether the controlled system was part of the dropped stage
if self.controlSystem.controlledSystem in droppedStage.components:
# If so delete the rocket's control system and remove any control system-induced time stepping modifications
print("Rocket's controlled system was on the dropped stage. Deactivating control system.")
self.controlSystem.restoreOriginalTimeStepping()
self.controlSystem = None
def _ensureBaseDragIsAccountedFor(self):
''' If no BoatTail exists at the bottom of the rocket, adds a zero-length boat tail. This is necessary b/c Boat Tail aero-functions are the ones that account for base drag '''
boatTailComponentAtBottomOfRocket = False
bottomStage = self.stages[-1]
for comp in reversed(bottomStage.components):
if isinstance(comp, BodyComponent):
if isinstance(comp, BoatTail):
boatTailComponentAtBottomOfRocket = True
break
if not boatTailComponentAtBottomOfRocket and self.addZeroLengthBoatTailsToAccountForBaseDrag:
if not self.silent:
print("Adding zero-length BoatTail to the bottom of current bottom stage ({}) to account for base drag".format(bottomStage.name))
# Create a zero-length, zero-mass boat tail to account for base drag
zeroInertia = Inertia(Vector(0,0,0), Vector(0,0,0), 0)
diameter = self.maxDiameter # TODO: Get the actual bottom-body-tube diameter from a future Stage.getRadius function
length = 0
position = bottomStage.getBottomInterfaceLocation()
boatTail = BoatTail(
diameter,
diameter,
length,
position,
zeroInertia,
self,
bottomStage,
"Auto-AddedZeroLengthBoatTail",
self.surfaceRoughness
)
initializeForceLogging(boatTail, "FakeRocketName.Auto-AddedZeroLengthBoatTail", self)
bottomStage.components.append(boatTail)
def _updateFinenessRatio(self):
''' Updates self.finenessRatio based on current BodyComponents in rocket stages '''
length = self.getLength()
maxDiameter = max([ stage.getMaxDiameter() for stage in self.stages ])
if maxDiameter == 0:
self.finenessRatio = None
else:
self.finenessRatio = length/maxDiameter
#### Component-buildup method for Force ####
def _getEnvironmentalConditions(self, time, state):
env = self.environment.getAirProperties(state.position, time)
# Neglect turbulent component of wind if required
if self.isUnderChute and self.turbulenceOffWhenUnderChute:
env = EnvironmentalConditions(
env.ASLAltitude,
env.Temp,
env.Pressure,
env.Density,
env.DynamicViscosity,
env.MeanWind,
env.MeanWind,
Vector(0, 0, 0),
)
return env
def _getAppliedForce(self, time, state):
''' Get the total force currently being experienced by the rocket, used by self.rigidBody to calculate the rocket's acceleration '''
### Precomputations and Logging ###
environment = self._getEnvironmentalConditions(time, state) # Get and log current air/wind properties
rocketInertia = self.getInertia(time, state) # Get and log current rocket inertia
if self.derivativeEvaluationLog is not None:
self.derivativeEvaluationLog.newLogRow(time)
self.derivativeEvaluationLog.logValue("Position(m)", state.position)
self.derivativeEvaluationLog.logValue("Velocity(m/s)", state.velocity)
### Component Forces ###
if not self.isUnderChute:
# Precompute and log
Mach = AeroParameters.getMachNumber(state, environment)
unitRe = AeroParameters.getReynoldsNumber(state, environment, 1.0)
AOA = AeroParameters.getTotalAOA(state, environment)
rollAngle = AeroParameters.getRollAngle(state, environment)
if self.derivativeEvaluationLog is not None:
self.derivativeEvaluationLog.logValue("Mach", Mach)
self.derivativeEvaluationLog.logValue("UnitRe", unitRe)
self.derivativeEvaluationLog.logValue("AOA(deg)", math.degrees(AOA))
self.derivativeEvaluationLog.logValue("RollAngle(deg)", rollAngle)
self.derivativeEvaluationLog.logValue("OrientationQuaternion", state.orientation)
self.derivativeEvaluationLog.logValue("AngularVelocity(rad/s)", state.angularVelocity)
# This function will be the inherited function CompositeObject.getAppliedForce
componentForces = self.getAppliedForce(state, time, environment, rocketInertia.CG)
else:
# When under chute, neglect forces from other components
componentForces = self.recoverySystem.getAppliedForce(state, time, environment, Vector(0,0,-1))
# Log the recovery system's applied force (Normally handled in CompositeObject.getAppliedForce)
if hasattr(self.recoverySystem, "forcesLog"):
self.recoverySystem.forcesLog.append(componentForces.force)
self.recoverySystem.momentsLog.append(componentForces.moment)
# Move Force-Moment system to rocket CG
componentForces = componentForces.getAt(rocketInertia.CG)
### Gravity ###
gravityForce = self.environment.getGravityForce(rocketInertia, state)
totalForce = componentForces + gravityForce
### Launch Rail ###
totalForce = self.environment.applyLaunchTowerForce(state, time, totalForce)
if self.derivativeEvaluationLog is not None:
self.derivativeEvaluationLog.logValue("Wind(m/s)", environment.Wind)
self.derivativeEvaluationLog.logValue("AirDensity(kg/m^3)", environment.Density)
self.derivativeEvaluationLog.logValue("CG(m)", rocketInertia.CG)
self.derivativeEvaluationLog.logValue("MOI(kg*m^2)", rocketInertia.MOI)
self.derivativeEvaluationLog.logValue("Mass(kg)", rocketInertia.mass)
CPZ = AeroFunctions._getCPZ(componentForces)
self.derivativeEvaluationLog.logValue("CPZ(m)", CPZ)
self.derivativeEvaluationLog.logValue("AeroF(N)", componentForces.force)
self.derivativeEvaluationLog.logValue("AeroM(Nm)", componentForces.moment)
self.derivativeEvaluationLog.logValue("GravityF(N)", gravityForce.force)
self.derivativeEvaluationLog.logValue("TotalF(N)", totalForce.force)
return totalForce
#### Driving / Controlling Simulation ####
def _logState(self):
'''
Logs the initial state of the rocket to the time step log
'''
state = self.rigidBody.state
time = self.rigidBody.time
if self.timeStepLog is not None:
self.timeStepLog.newLogRow(time)
self.timeStepLog.logValue("Position(m)", state.position)
self.timeStepLog.logValue("Velocity(m/s)", state.velocity)
try: # 6DoF Mode
self.timeStepLog.logValue("OrientationQuaternion", state.orientation)
self.timeStepLog.logValue("AngularVelocity(rad/s)", state.angularVelocity)
# Also log NED Tait-Bryan 3-2-1 z-y-x Euler Angles if in 6DoF mode
globalOrientation = state.orientation
orientationOfNEDFrameInGlobalFrame = self.environment.earthModel.getInertialToNEDFrameRotation(*state.position)
orientationRelativeToNEDFrame = orientationOfNEDFrameInGlobalFrame.conjugate() * globalOrientation
eulerAngles = orientationRelativeToNEDFrame.toEulerAngles()
self.timeStepLog.logValue("EulerAngle(rad)", eulerAngles)
except AttributeError:
pass # 3DoF mode
# Print the current time and altitude to the console
altitude = self.environment.earthModel.getAltitude(*state.position)
consoleOutput = "{:<8.4f} {:>6.5f}".format(time, altitude)
print(consoleOutput)
def _runControlSystem(self):
'''
Attempts to run the rocket control system (only runs if it's time to run again, based on its updated rate) (updating target positions for actuators)
'''
if self.controlSystem != None and not self.isUnderChute:
state = self.rigidBody.state
time = self.rigidBody.time
environment = self._getEnvironmentalConditions(time, state)
### Run Control Loop ###
self.controlSystem.runControlLoopIfRequired(time, state, environment)
def timeStep(self, dt: float):
'''
Tells the simulation to take a time step of size dt.
Usually called by functions like `MAPLEAF.SimulationRunners.Simulation.run()`
Returns:
* timeStepAdaptationFactor: (float) indicates the factor by which the adaptive time stepping method would like to change the timestep for the next timestep (1.0 for non-adaptive methods)
* dt: (float) actual size of time step taken. Adaptive methods will override the dt asked for if the predicted error for a time step is over their error threshold.
'''
# Stop the rocket from sliding off the bottom of the launch rail
self.rigidBody.state = self.environment.applyLaunchRailMotionConstraints(self.rigidBody.state, self.rigidBody.time)
# Trigger any events that occurred during the last time step
estimatedTimeToNextEvent, accuratePrediction = self.simEventDetector.triggerEvents()
# If required, override time step to accurately resolve upcoming discrete events
if "Adapt" in self.rigidBody.integrate.method and estimatedTimeToNextEvent < dt:
if accuratePrediction:
# For time-deterministic events, just set the time step to ever so slightly past the event
newDt = estimatedTimeToNextEvent + 1e-5
print("Rocket + SimEventDetector overriding time step from {} to {} to accurately trigger resolve time-deterministic event.".format(dt, newDt))
dt = newDt
else:
# For time-nondeterministic events, slowly approach the event
newDt = max(estimatedTimeToNextEvent/1.5, self.eventTimeStep)
estimatedOccurenceTime = self.rigidBody.time + estimatedTimeToNextEvent
print("Rocket + SimEventDetector overriding time step from {} to {} to accurately resolve upcoming event. Estimated occurence at: {}".format(dt, newDt, estimatedOccurenceTime))
dt = newDt
self._runControlSystem()
self._logState()
# Take timestep
integrationResult = self.rigidBody.timeStep(dt)
# If required, log estimated integration error
if "Adapt" in self.rigidBody.integrate.method and self.timeStepLog is not None:
self.timeStepLog.logValue("EstimatedIntegrationError", integrationResult.errorMagEstimate)
return integrationResult
def _switchTo3DoF(self):
''' Switch to 3DoF simulation after recovery system is deployed '''
print("Switching to 3DoF simulation")
new3DoFState = RigidBodyState_3DoF(self.rigidBody.state.position, self.rigidBody.state.velocity)
# Re-read time discretization in case an adaptive method has been selected while using a fixed-update rate control system - in that case, want to switch back to adaptive time stepping for the recovery (uncontrolled) portion of the flight
originalTimeDiscretization = self.rocketDictReader.getString("SimControl.timeDiscretization")
if self.simRunner != None:
self.rigidBody = RigidBody_3DoF(
new3DoFState,
self._getAppliedForce,
self.getMass,
startTime=self.rigidBody.time,
integrationMethod=originalTimeDiscretization,
discardedTimeStepCallback=self.simRunner.discardForceLogsForPreviousTimeStep,
simDefinition=self.simDefinition
)
else:
self.rigidBody = RigidBody_3DoF(
new3DoFState,
self._getAppliedForce,
self.getMass,
startTime=self.rigidBody.time,
integrationMethod=originalTimeDiscretization,
simDefinition=self.simDefinition
)
#### After Simulation ####
def writeLogsToFile(self, directory="."):
logfilePaths = []
if self.timeStepLog is not None:
rocketName = self.components[0].name # Rocket is named after its top stage
path = os.path.join(directory, "{}_timeStepLog.csv".format(rocketName))
# Time step log
if self.timeStepLog.writeToCSV(path):
logfilePaths.append(path)
# Derivative evaluation log
if self.derivativeEvaluationLog is not None:
path = os.path.join(directory, "{}_derivativeEvaluationLog.csv".format(rocketName))
if self.derivativeEvaluationLog.writeToCSV(path):
logfilePaths.append(path)
# Calculate aerodynamic coefficients if desired
if self.loggingLevel > 2:
expandedLogPath = Logging.postProcessForceEvalLog(path, refArea=self.Aref, refLength=self.maxDiameter)
logfilePaths.append(expandedLogPath)
# Control system log
if self.controlSystem != None:
if self.controlSystem.log != None:
controlSystemLogPath = self.controlSystem.writeLogsToFile(directory)
logfilePaths.append(controlSystemLogPath)
return logfilePathsClasses
class Rocket (rocketDictReader, silent=False, stageToInitialize=None, simRunner=None, environment=None)-
Class used to represent a single flying rigid body composed of
Stageobjects. New instances of this class are also created to model the flight of dropped stages.Initialization of Rocket(s) is most easily completed through an instance of Simulation To get a single Rocket object, initialize a Simulation and call
Simulation.createRocket().
This will return a Rocket initialized on the pad with all its stages, ready for flight.If initializing manually, can either provide fileName or simDefinition. If a simDefinition is provided, it will be used and fileName will be ignored.
Inputs:
- rocketDictReader:
(
SubDictReader) SubDictReader pointed at the "Rocket" dictionary of the desired simulation definition file. - silent: (bool) controls console output
- stageToInitialize: (int or None) controls whether to initialize a complete Rocket or a single (usually dropped) stage. None = initialize complete rocket. n = initialize only stage n, where n >= 1.
- simRunner:
(
Simulation) reference to the current simulation driver/runner - environment:
(
Environment) environment model from which the rocket will retrieve atmospheric properties and wind speeds
Expand source code
class Rocket(CompositeObject): ''' Class used to represent a single flying rigid body composed of `MAPLEAF.Rocket.Stage` objects. New instances of this class are also created to model the flight of dropped stages. ''' #### Initialization #### def __init__(self, rocketDictReader, silent=False, stageToInitialize=None, simRunner=None, environment=None): ''' Initialization of Rocket(s) is most easily completed through an instance of Simulation To get a single Rocket object, initialize a Simulation and call `MAPLEAF.SimulationRunners.Simulation.createRocket()`. This will return a Rocket initialized on the pad with all its stages, ready for flight. If initializing manually, can either provide fileName or simDefinition. If a simDefinition is provided, it will be used and fileName will be ignored. Inputs: * rocketDictReader: (`MAPLEAF.IO.SubDictReader`) SubDictReader pointed at the "Rocket" dictionary of the desired simulation definition file. * silent: (bool) controls console output * stageToInitialize: (int or None) controls whether to initialize a complete Rocket or a single (usually dropped) stage. None = initialize complete rocket. n = initialize only stage n, where n >= 1. * simRunner: (`MAPLEAF.SimulationRunners.Simulation`) reference to the current simulation driver/runner * environment: (`MAPLEAF.ENV.Environment`) environment model from which the rocket will retrieve atmospheric properties and wind speeds ''' self.rocketDictReader = rocketDictReader self.simDefinition = rocketDictReader.simDefinition self.simRunner = simRunner ''' Parent instance of `MAPLEAF.SimulationRunners.Simulation` (or derivative sim runner). This is usually the object that has created the current instance of Rocket. ''' self.environment = environment ''' Instance of `MAPLEAF.ENV.Environment` ''' if self.environment == None: # If no environment is passed in, create one self.environment = Environment(self.simDefinition, silent=silent) self.name = rocketDictReader.getString("name") self.silent = silent ''' Controls output to console ''' self.stage = stageToInitialize ''' If controls whether the whole rocket is initialized (if == None), or a single stage is initialized (Integer stage number) ''' self.stages = [] ''' A list of `MAPLEAF.Rocket.Stage` objects that make up the rocket, ordered from top to bottom. Populated by `_initializeStages`. ''' self.recoverySystem = None ''' Reference to the current Rocket's (which can represent a dropped stage) recovery system. Only a single recovery system is allowed per stage. Set in `MAPLEAF.Rocket.RecoverySystem.__init__` ''' self.rigidBody = None ''' (`MAPLEAF.Motion.RigidBody` or `MAPLEAF.Motion.RigidBody_3DoF`) Responsible for motion integration. Set in `_initializeRigidBody()`. ''' self.isUnderChute = False ''' (bool) Controlled by `MAPLEAF.Rocket.Recovery.RecoverySystem._deployNextStage()` ''' self.mainChuteDeployTime = None ''' (float) Filled in during flight by `MAPLEAF.Rocket.Recovery.RecoverySystem._deployNextStage()` ''' self.engineShutOffTime = None ''' (float) Filled in by `MAPLEAF.Rocket.Propulsion.TabulatedMotor.__init__()` upon initialization ''' self.turbulenceOffWhenUnderChute = rocketDictReader.getBool("Environment.turbulenceOffWhenUnderChute") ''' (bool) ''' self.maxDiameter = self._getMaxBodyTubeDiameter() ''' (float) Holds maximum constant-size body tube diameter, from bodytube components in stages ''' self.Aref = math.pi * self.maxDiameter**2 / 4 ''' Reference area for force and moment coefficients. Maximum rocket cross-sectional area. Remains constant during flight to retain a 1:1 relationship b/w coefficients in different parts of flight. Always based on the maximum body tube diameter in the fully-assembled rocket. ''' # TODO: Remove self.targetLocation = None self.simEventDetector = SimEventDetector(self) ''' (`MAPLEAF.Rocket.SimEventDetector`) Used to trigger things like recovery systems and staging ''' self.eventTimeStep = rocketDictReader.getFloat("SimControl.TimeStepAdaptation.eventTimingAccuracy") ''' If using an adaptive time stepping method, the time step will be overridden near non-time-deterministic discrete events, possibly all the way down to this minimum value ''' self.addZeroLengthBoatTailsToAccountForBaseDrag = rocketDictReader.getBool("Aero.addZeroLengthBoatTailsToAccountForBaseDrag") ''' Controls whether zero-length boat tails are automatically added to the bottom of rockets without them, to make sure base drag is accounted for ''' self.fullyTurbulentBL = rocketDictReader.getBool("Aero.fullyTurbulentBL") ''' Controls whether skin friction is solved assuming a fully turbulent BL or using laminar/transitional flow at lower Reynolds numbers ''' self.surfaceRoughness = rocketDictReader.getFloat("Aero.surfaceRoughness") ''' Default surface roughness for all rocket components ''' self.finenessRatio = None ''' Used in some aerodynamic functions. Updated after initializing subcomponents, and throughout the flight. None if no BodyComponent(s) are present in the rocket ''' self.engineShutOff = False '''Used to shut off engines in MAPLEAF.Rocket.Propulsion.DefinedMotor class. Currently set in MAPLE_AF.GNC.Navigation''' #### Init Hardware in the loop #### subDicts = rocketDictReader.getImmediateSubDicts() if "Rocket.HIL" in subDicts: self.hardwareInTheLoopControl = "yes" quatUpdateRate = rocketDictReader.getInt("HIL.quatUpdateRate") posUpdateRate = rocketDictReader.getInt("HIL.posUpdateRate") velUpdateRate = rocketDictReader.getInt("HIL.velUpdateRate") teensyComPort = rocketDictReader.getString("HIL.teensyComPort") imuComPort = rocketDictReader.getString("HIL.imuComPort") teensyBaudrate = rocketDictReader.getInt("HIL.teensyBaudrate") imuBaudrate = rocketDictReader.getInt("HIL.imuBaudrate") self.hilInterface = HILInterface(quatUpdateRate,posUpdateRate,velUpdateRate, teensyComPort, imuComPort, teensyBaudrate, imuBaudrate) else: self.hardwareInTheLoopControl = "no" #### Initialize Logging #### self.timeStepLog = None ''' Log containing one entry per time step, logs rocket state. None if logging level == 0 ''' self.derivativeEvaluationLog = None ''' Log containing one entry per rocket motion derivative evaluation, contains component forces. None if logging level < 2 ''' loggingLevel = int(self.simDefinition.getValue("SimControl.loggingLevel")) self.loggingLevel = loggingLevel if loggingLevel > 0: # Create the time step log and add columns to track the rocket state between each time step self.timeStepLog = TimeStepLog() zeroVector = Vector(0,0,0) self.timeStepLog.addColumn("Position(m)", zeroVector) self.timeStepLog.addColumn("Velocity(m/s)", zeroVector) self.timeStepLog.addColumn("OrientationQuaternion", Quaternion(0,0,0,0)) self.timeStepLog.addColumn("EulerAngle(rad)", zeroVector) self.timeStepLog.addColumn("AngularVelocity(rad/s)", zeroVector) if "Adapt" in self.simDefinition.getValue("SimControl.timeDiscretization"): self.timeStepLog.addColumn("EstimatedIntegrationError", 0) if loggingLevel > 1: self.derivativeEvaluationLog = Log() zeroVector = Vector(0,0,0) self.derivativeEvaluationLog.addColumn("Position(m)", zeroVector) self.derivativeEvaluationLog.addColumn("Velocity(m/s)", zeroVector) self.derivativeEvaluationLog.addColumn("OrientationQuaternion", Quaternion(0,0,0,0)) self.derivativeEvaluationLog.addColumn("AngularVelocity(rad/s)", zeroVector) self.derivativeEvaluationLog.addColumn("CG(m)", zeroVector) self.derivativeEvaluationLog.addColumn("MOI(kg*m^2)", zeroVector) self.derivativeEvaluationLog.addColumn("Mass(kg)", 0) self.derivativeEvaluationLog.addColumn("Wind(m/s)", zeroVector) self.derivativeEvaluationLog.addColumn("AirDensity(kg/m^3)", 0) self.derivativeEvaluationLog.addColumn("Mach", 0) self.derivativeEvaluationLog.addColumn("UnitRe", 0) self.derivativeEvaluationLog.addColumn("AOA(deg)", 0) self.derivativeEvaluationLog.addColumn("RollAngle(deg)", 0) self.derivativeEvaluationLog.addColumn("CPZ(m)", 0) self.derivativeEvaluationLog.addColumn("AeroF(N)", zeroVector) self.derivativeEvaluationLog.addColumn("AeroM(Nm)", zeroVector) self.derivativeEvaluationLog.addColumn("GravityF(N)", zeroVector) self.derivativeEvaluationLog.addColumn("TotalF(N)", zeroVector) #### Init Components #### self._createStages() self._initializeRigidBody() self._switchToStatefulRigidBodyIfRequired() self._sortStagesAndComponents() self._initializeStagingTriggers() self._precomputeComponentProperties() #### Init Parent classes #### CompositeObject.__init__(self, self.stages) self._updateFinenessRatio() # Adjust rigid body state position to correspond to the rocket's CG instead of nose cone tip position self._moveStatePositionToCG() #### Init Guidance/Navigation/Control System (if required) #### self.controlSystem = None ''' None for uncontrolled rockets. `MAPLEAF.GNC.ControlSystems.RocketControlSystem` for controlled rockets ''' if ( rocketDictReader.tryGetString("ControlSystem.controlledSystem") != None or rocketDictReader.tryGetString("ControlSystem.MomentController.Type") == "IdealMomentController") and stageToInitialize == None: # Only create a control system if this is NOT a dropped stage ControlSystemDictReader = SubDictReader("Rocket.ControlSystem", simDefinition=self.simDefinition) controlSystemLogging = loggingLevel > 3 self.controlSystem = RocketControlSystem(ControlSystemDictReader, self, log=controlSystemLogging, silent=silent) def _getMaxBodyTubeDiameter(self): ''' Gets max body tube diameter directly from config file ''' stageDicts = self._getStageSubDicts() maxDiameter = 0 for stageDict in stageDicts: componentDicts = self.rocketDictReader.getImmediateSubDicts(stageDict) for componentDict in componentDicts: className = self.rocketDictReader.getString(componentDict + ".class") if className == "Bodytube": diameter = self.rocketDictReader.getFloat(componentDict + ".outerDiameter") maxDiameter = max(maxDiameter, diameter) return maxDiameter def _getStageSubDicts(self): # Get all immediate subdictionaries of 'Rocket' stageDicts = self.rocketDictReader.getImmediateSubDicts() # Assume all subdictionaries represent rocket stages except for these exceptions nonStageSubDicts = [ "Rocket.ControlSystem", "Rocket.HIL", "Rocket.Aero" ] # Remove them from the list if they're in it for dictName in nonStageSubDicts: if dictName in stageDicts: stageDicts.remove(dictName) return stageDicts def _initializeRigidBody(self): #### Get initial kinematic state (in launch tower frame) #### initPos = self.rocketDictReader.getVector("position") initVel = self.rocketDictReader.getVector("velocity") # Check whether precise initial orientation has been specified rotationAxis = self.rocketDictReader.tryGetVector("rotationAxis", defaultValue=None) if rotationAxis != None: rotationAngle = math.radians(self.rocketDictReader.getFloat("rotationAngle")) initOrientation = Quaternion(rotationAxis, rotationAngle) else: # Calculate initial orientation quaternion in launch tower frame initialDirection = self.rocketDictReader.getVector("initialDirection").normalize() angleFromVertical = Vector(0,0,1).angle(initialDirection) rotationAxis = Vector(0,0,1).crossProduct(initialDirection) initOrientation = Quaternion(rotationAxis, angleFromVertical) initAngVel = AngularVelocity(rotationVector=self.rocketDictReader.getVector("angularVelocity")) initState_launchTowerFrame = RigidBodyState(initPos, initVel, initOrientation, initAngVel) # Convert to the global inertial frame initState_globalInertialFrame = self.environment.convertInitialStateToGlobalFrame(initState_launchTowerFrame) # Get desired time discretization method timeDisc = self.rocketDictReader.getString("SimControl.timeDiscretization") #TODO: Check for additional parameters to integrate - if they exist create a StatefulRigidBody + RocketState instead! # Ask each rocket component whether it would like to add parameters to integrate after all the components have been initialized discardDtCallback = None if (self.simRunner == None) else self.simRunner.discardForceLogsForPreviousTimeStep #### Initialize the rigid body #### self.rigidBody = RigidBody( initState_globalInertialFrame, self._getAppliedForce, self.getInertia, integrationMethod=timeDisc, discardedTimeStepCallback=discardDtCallback, simDefinition=self.simDefinition ) def _createStages(self): ''' Initialize each of the stages and all of their subcomponents. ''' stageDicts = self._getStageSubDicts() # If we're initializing a dropped stage, figure out which one if self.stage != None: stageNumbers = [] stageNumberSet = set() for stageDict in stageDicts: stageNumber = self.rocketDictReader.getFloat(stageDict + ".stageNumber") stageNumbers.append(stageNumber) stageNumberSet.add(stageNumber) if len(stageNumbers) != len(stageNumberSet): raise ValueError("For multi-stage rockets, each stage must have a unique stage number. Set the Rocket.StageName.stageNumber value for each stage. 0 for first stage, 1 for second, etc...") stageNumbers.sort() stageToInitialize = stageNumbers[self.stage] # Initialize Stage(s) initializingAllStages = (self.stage == None) for stageDictionary in stageDicts: stageDictReader = SubDictReader(stageDictionary, self.simDefinition) stageNumber = stageDictReader.getFloat("stageNumber") if initializingAllStages or stageNumber == stageToInitialize: newStage = Stage(stageDictReader, self) self.stages.append(newStage) if newStage.name not in self.__dict__: # Avoid clobbering existing info setattr(self, newStage.name, newStage) # Make stage available as rocket.stageName def _sortStagesAndComponents(self): # Create Planar Interfaces b/w components inside stages for stage in self.stages: stage.components = PlanarInterface.sortByZLocation(stage.components, self.rigidBody.state) stage.componentInterfaces = PlanarInterface.createPlanarComponentInterfaces(stage.components) # Create planar interfaces b/w stages self.stages = PlanarInterface.sortByZLocation(self.stages, self.rigidBody.state) self.stageInterfaces = PlanarInterface.createPlanarComponentInterfaces(self.stages) if self.maxDiameter > 0: # Only run this if we're running a real rocket with body tubes self._ensureBaseDragIsAccountedFor() def _initializeStagingTriggers(self): ''' Set up trigger conditions for staging ''' # Self.stage is not passed in if the current instance represents a rocket ready to launch - then we have to set up staging events if self.stage == None: for stageIndex in range(len(self.stages)): stage = self.stages[stageIndex] if stage.separationConditionType != 'None': self.simEventDetector.subscribeToEvent( stage.separationConditionType, self._stageSeparation, stage.separationConditionValue, triggerDelay=stage.separationDelay ) if stageIndex != len(self.stages)-1: # Set all upper stage motors to ignite a very long time in the future stage.motor.updateIgnitionTime(1000000000, fakeValue=True) else: # Otherwise this rocket object is representing a single dropped stage, and no stage separations are necessary # Motor is burned out self.stages[0].motor.updateIgnitionTime(-1000000000, fakeValue=True) def _switchToStatefulRigidBodyIfRequired(self): ''' Query all of the rocket components to see if any of them are stateful by attempting to call their getExtraParametersToIntegrate function If the rocket contains stateful components, the rocket state is converted to a StateList and all of these state variables requested by components are added to it Otherwise, nothing changes and the rocket state remains a RigidBodyState ''' varNames = [] initVals = [] derivativeFuncs = [] # Query all of the components for stage in self.stages: for component in stage.components: try: paramNames, initValues, derivativeFunctions = component.getExtraParametersToIntegrate() varNames += paramNames initVals += initValues derivativeFuncs += derivativeFunctions except AttributeError: pass # No extra parameters to integrate # If any of the components are stateful, keep track of their states in the main rocket state if len(varNames) > 0: if len(varNames) != len(initVals) or len(initVals) != len(derivativeFuncs): raise ValueError("ERROR: Mismatch in number of extra parameters names ({}), init values({}), and derivative functions({}) to integrate".format(len(varNames), len(initVals), len(derivativeFuncs))) # Switch to a stateful rigid body initState = self.rigidBody.state forceFunc = self.rigidBody.forceFunc inertiaFunc = self.rigidBody.inertiaFunc integrationMethod = self.rocketDictReader.getString("SimControl.timeDiscretization") discardDtCallback = None if (self.simRunner == None) else self.simRunner.discardForceLogsForPreviousTimeStep self.rigidBody = StatefulRigidBody( initState, forceFunc, inertiaFunc, integrationMethod=integrationMethod, discardedTimeStepCallback=discardDtCallback, simDefinition=self.simDefinition ) # Add the additional state variables for i in range(len(varNames)): self.rigidBody.addStateVariable(varNames[i], initVals[i], derivativeFuncs[i]) def _precomputeComponentProperties(self): for stage in self.stages: for component in stage.components: try: component.precomputeProperties() except AttributeError: pass def _moveStatePositionToCG(self): ''' Moves self.rigidBody.state.position to have it represent the rocket's initial CG position, not the initial nose cone position ''' initInertia = self.getInertia(0, self.rigidBody.state) CGPosition_wrtNoseCone_localFrame = initInertia.CG CGPosition__wrtNoseCone_globalFrame = self.rigidBody.state.orientation.rotate(CGPosition_wrtNoseCone_localFrame) CGPosition_globalFrame = self.rigidBody.state.position + CGPosition__wrtNoseCone_globalFrame self.rigidBody.state.position = CGPosition_globalFrame def getLength(self): totalLength = 0 for stage in self.stages: try: totalLength += stage.getLength() except TypeError: pass # Stage Length was None - no body components in stage return totalLength def plotShape(self): plt.figure() plt.gca().set_aspect('equal') rocketInertia = self.getInertia(0, self.rigidBody.state) TotalCG = rocketInertia.CG.Z TotalMass = rocketInertia.mass TotalCGplt = plt.plot(TotalCG, 0, color='b', marker='d', label='Total CG', linestyle='None') CGsubZ = [] CGsubY = [] plt.title('Total Rocket CG: %10.4f m \n Total Rocket Mass: %10.4f Kg' % (TotalCG,TotalMass) ) for stage in self.stages: zCGs, yCGs = stage.plotShape() # Add subcomponents CGs to arrays CGsubZ += zCGs CGsubY += yCGs SubCGplt = plt.plot(CGsubZ, CGsubY, color='g', marker='.', label='Subcomponent CG', linestyle='None') legendHeight = self.maxDiameter plt.legend(loc='upper center', bbox_to_anchor = (0.5,-1.05)) plt.show() #### Stage Separation #### def _stageSeparation(self): print("Stage {} Separation".format(self.simRunner.stagingIndex + 1)) # Initialize dropped stage as a new rocket self.simRunner.createNewDetachedStage() # Drop stage from current rocket self._dropStage() # Ignite next motor (set ignition time to the time of stage separation) currentTime = self.rigidBody.time self.stages[0].motor.updateIgnitionTime(currentTime) self._ensureBaseDragIsAccountedFor() self._updateFinenessRatio() def _dropStage(self, stageIndex=-1): droppedStage = self.stages.pop(stageIndex) delattr(self, droppedStage.name) self.recomputeFixedMassInertia() if self.controlSystem != None: # Check whether the controlled system was part of the dropped stage if self.controlSystem.controlledSystem in droppedStage.components: # If so delete the rocket's control system and remove any control system-induced time stepping modifications print("Rocket's controlled system was on the dropped stage. Deactivating control system.") self.controlSystem.restoreOriginalTimeStepping() self.controlSystem = None def _ensureBaseDragIsAccountedFor(self): ''' If no BoatTail exists at the bottom of the rocket, adds a zero-length boat tail. This is necessary b/c Boat Tail aero-functions are the ones that account for base drag ''' boatTailComponentAtBottomOfRocket = False bottomStage = self.stages[-1] for comp in reversed(bottomStage.components): if isinstance(comp, BodyComponent): if isinstance(comp, BoatTail): boatTailComponentAtBottomOfRocket = True break if not boatTailComponentAtBottomOfRocket and self.addZeroLengthBoatTailsToAccountForBaseDrag: if not self.silent: print("Adding zero-length BoatTail to the bottom of current bottom stage ({}) to account for base drag".format(bottomStage.name)) # Create a zero-length, zero-mass boat tail to account for base drag zeroInertia = Inertia(Vector(0,0,0), Vector(0,0,0), 0) diameter = self.maxDiameter # TODO: Get the actual bottom-body-tube diameter from a future Stage.getRadius function length = 0 position = bottomStage.getBottomInterfaceLocation() boatTail = BoatTail( diameter, diameter, length, position, zeroInertia, self, bottomStage, "Auto-AddedZeroLengthBoatTail", self.surfaceRoughness ) initializeForceLogging(boatTail, "FakeRocketName.Auto-AddedZeroLengthBoatTail", self) bottomStage.components.append(boatTail) def _updateFinenessRatio(self): ''' Updates self.finenessRatio based on current BodyComponents in rocket stages ''' length = self.getLength() maxDiameter = max([ stage.getMaxDiameter() for stage in self.stages ]) if maxDiameter == 0: self.finenessRatio = None else: self.finenessRatio = length/maxDiameter #### Component-buildup method for Force #### def _getEnvironmentalConditions(self, time, state): env = self.environment.getAirProperties(state.position, time) # Neglect turbulent component of wind if required if self.isUnderChute and self.turbulenceOffWhenUnderChute: env = EnvironmentalConditions( env.ASLAltitude, env.Temp, env.Pressure, env.Density, env.DynamicViscosity, env.MeanWind, env.MeanWind, Vector(0, 0, 0), ) return env def _getAppliedForce(self, time, state): ''' Get the total force currently being experienced by the rocket, used by self.rigidBody to calculate the rocket's acceleration ''' ### Precomputations and Logging ### environment = self._getEnvironmentalConditions(time, state) # Get and log current air/wind properties rocketInertia = self.getInertia(time, state) # Get and log current rocket inertia if self.derivativeEvaluationLog is not None: self.derivativeEvaluationLog.newLogRow(time) self.derivativeEvaluationLog.logValue("Position(m)", state.position) self.derivativeEvaluationLog.logValue("Velocity(m/s)", state.velocity) ### Component Forces ### if not self.isUnderChute: # Precompute and log Mach = AeroParameters.getMachNumber(state, environment) unitRe = AeroParameters.getReynoldsNumber(state, environment, 1.0) AOA = AeroParameters.getTotalAOA(state, environment) rollAngle = AeroParameters.getRollAngle(state, environment) if self.derivativeEvaluationLog is not None: self.derivativeEvaluationLog.logValue("Mach", Mach) self.derivativeEvaluationLog.logValue("UnitRe", unitRe) self.derivativeEvaluationLog.logValue("AOA(deg)", math.degrees(AOA)) self.derivativeEvaluationLog.logValue("RollAngle(deg)", rollAngle) self.derivativeEvaluationLog.logValue("OrientationQuaternion", state.orientation) self.derivativeEvaluationLog.logValue("AngularVelocity(rad/s)", state.angularVelocity) # This function will be the inherited function CompositeObject.getAppliedForce componentForces = self.getAppliedForce(state, time, environment, rocketInertia.CG) else: # When under chute, neglect forces from other components componentForces = self.recoverySystem.getAppliedForce(state, time, environment, Vector(0,0,-1)) # Log the recovery system's applied force (Normally handled in CompositeObject.getAppliedForce) if hasattr(self.recoverySystem, "forcesLog"): self.recoverySystem.forcesLog.append(componentForces.force) self.recoverySystem.momentsLog.append(componentForces.moment) # Move Force-Moment system to rocket CG componentForces = componentForces.getAt(rocketInertia.CG) ### Gravity ### gravityForce = self.environment.getGravityForce(rocketInertia, state) totalForce = componentForces + gravityForce ### Launch Rail ### totalForce = self.environment.applyLaunchTowerForce(state, time, totalForce) if self.derivativeEvaluationLog is not None: self.derivativeEvaluationLog.logValue("Wind(m/s)", environment.Wind) self.derivativeEvaluationLog.logValue("AirDensity(kg/m^3)", environment.Density) self.derivativeEvaluationLog.logValue("CG(m)", rocketInertia.CG) self.derivativeEvaluationLog.logValue("MOI(kg*m^2)", rocketInertia.MOI) self.derivativeEvaluationLog.logValue("Mass(kg)", rocketInertia.mass) CPZ = AeroFunctions._getCPZ(componentForces) self.derivativeEvaluationLog.logValue("CPZ(m)", CPZ) self.derivativeEvaluationLog.logValue("AeroF(N)", componentForces.force) self.derivativeEvaluationLog.logValue("AeroM(Nm)", componentForces.moment) self.derivativeEvaluationLog.logValue("GravityF(N)", gravityForce.force) self.derivativeEvaluationLog.logValue("TotalF(N)", totalForce.force) return totalForce #### Driving / Controlling Simulation #### def _logState(self): ''' Logs the initial state of the rocket to the time step log ''' state = self.rigidBody.state time = self.rigidBody.time if self.timeStepLog is not None: self.timeStepLog.newLogRow(time) self.timeStepLog.logValue("Position(m)", state.position) self.timeStepLog.logValue("Velocity(m/s)", state.velocity) try: # 6DoF Mode self.timeStepLog.logValue("OrientationQuaternion", state.orientation) self.timeStepLog.logValue("AngularVelocity(rad/s)", state.angularVelocity) # Also log NED Tait-Bryan 3-2-1 z-y-x Euler Angles if in 6DoF mode globalOrientation = state.orientation orientationOfNEDFrameInGlobalFrame = self.environment.earthModel.getInertialToNEDFrameRotation(*state.position) orientationRelativeToNEDFrame = orientationOfNEDFrameInGlobalFrame.conjugate() * globalOrientation eulerAngles = orientationRelativeToNEDFrame.toEulerAngles() self.timeStepLog.logValue("EulerAngle(rad)", eulerAngles) except AttributeError: pass # 3DoF mode # Print the current time and altitude to the console altitude = self.environment.earthModel.getAltitude(*state.position) consoleOutput = "{:<8.4f} {:>6.5f}".format(time, altitude) print(consoleOutput) def _runControlSystem(self): ''' Attempts to run the rocket control system (only runs if it's time to run again, based on its updated rate) (updating target positions for actuators) ''' if self.controlSystem != None and not self.isUnderChute: state = self.rigidBody.state time = self.rigidBody.time environment = self._getEnvironmentalConditions(time, state) ### Run Control Loop ### self.controlSystem.runControlLoopIfRequired(time, state, environment) def timeStep(self, dt: float): ''' Tells the simulation to take a time step of size dt. Usually called by functions like `MAPLEAF.SimulationRunners.Simulation.run()` Returns: * timeStepAdaptationFactor: (float) indicates the factor by which the adaptive time stepping method would like to change the timestep for the next timestep (1.0 for non-adaptive methods) * dt: (float) actual size of time step taken. Adaptive methods will override the dt asked for if the predicted error for a time step is over their error threshold. ''' # Stop the rocket from sliding off the bottom of the launch rail self.rigidBody.state = self.environment.applyLaunchRailMotionConstraints(self.rigidBody.state, self.rigidBody.time) # Trigger any events that occurred during the last time step estimatedTimeToNextEvent, accuratePrediction = self.simEventDetector.triggerEvents() # If required, override time step to accurately resolve upcoming discrete events if "Adapt" in self.rigidBody.integrate.method and estimatedTimeToNextEvent < dt: if accuratePrediction: # For time-deterministic events, just set the time step to ever so slightly past the event newDt = estimatedTimeToNextEvent + 1e-5 print("Rocket + SimEventDetector overriding time step from {} to {} to accurately trigger resolve time-deterministic event.".format(dt, newDt)) dt = newDt else: # For time-nondeterministic events, slowly approach the event newDt = max(estimatedTimeToNextEvent/1.5, self.eventTimeStep) estimatedOccurenceTime = self.rigidBody.time + estimatedTimeToNextEvent print("Rocket + SimEventDetector overriding time step from {} to {} to accurately resolve upcoming event. Estimated occurence at: {}".format(dt, newDt, estimatedOccurenceTime)) dt = newDt self._runControlSystem() self._logState() # Take timestep integrationResult = self.rigidBody.timeStep(dt) # If required, log estimated integration error if "Adapt" in self.rigidBody.integrate.method and self.timeStepLog is not None: self.timeStepLog.logValue("EstimatedIntegrationError", integrationResult.errorMagEstimate) return integrationResult def _switchTo3DoF(self): ''' Switch to 3DoF simulation after recovery system is deployed ''' print("Switching to 3DoF simulation") new3DoFState = RigidBodyState_3DoF(self.rigidBody.state.position, self.rigidBody.state.velocity) # Re-read time discretization in case an adaptive method has been selected while using a fixed-update rate control system - in that case, want to switch back to adaptive time stepping for the recovery (uncontrolled) portion of the flight originalTimeDiscretization = self.rocketDictReader.getString("SimControl.timeDiscretization") if self.simRunner != None: self.rigidBody = RigidBody_3DoF( new3DoFState, self._getAppliedForce, self.getMass, startTime=self.rigidBody.time, integrationMethod=originalTimeDiscretization, discardedTimeStepCallback=self.simRunner.discardForceLogsForPreviousTimeStep, simDefinition=self.simDefinition ) else: self.rigidBody = RigidBody_3DoF( new3DoFState, self._getAppliedForce, self.getMass, startTime=self.rigidBody.time, integrationMethod=originalTimeDiscretization, simDefinition=self.simDefinition ) #### After Simulation #### def writeLogsToFile(self, directory="."): logfilePaths = [] if self.timeStepLog is not None: rocketName = self.components[0].name # Rocket is named after its top stage path = os.path.join(directory, "{}_timeStepLog.csv".format(rocketName)) # Time step log if self.timeStepLog.writeToCSV(path): logfilePaths.append(path) # Derivative evaluation log if self.derivativeEvaluationLog is not None: path = os.path.join(directory, "{}_derivativeEvaluationLog.csv".format(rocketName)) if self.derivativeEvaluationLog.writeToCSV(path): logfilePaths.append(path) # Calculate aerodynamic coefficients if desired if self.loggingLevel > 2: expandedLogPath = Logging.postProcessForceEvalLog(path, refArea=self.Aref, refLength=self.maxDiameter) logfilePaths.append(expandedLogPath) # Control system log if self.controlSystem != None: if self.controlSystem.log != None: controlSystemLogPath = self.controlSystem.writeLogsToFile(directory) logfilePaths.append(controlSystemLogPath) return logfilePathsAncestors
Instance variables
var Aref-
Reference area for force and moment coefficients. Maximum rocket cross-sectional area. Remains constant during flight to retain a 1:1 relationship b/w coefficients in different parts of flight. Always based on the maximum body tube diameter in the fully-assembled rocket.
var addZeroLengthBoatTailsToAccountForBaseDrag-
Controls whether zero-length boat tails are automatically added to the bottom of rockets without them, to make sure base drag is accounted for
var controlSystem-
None for uncontrolled rockets.
RocketControlSystemfor controlled rockets var derivativeEvaluationLog-
Log containing one entry per rocket motion derivative evaluation, contains component forces. None if logging level < 2
var engineShutOff-
Used to shut off engines in MAPLEAF.Rocket.Propulsion.DefinedMotor class. Currently set in MAPLE_AF.GNC.Navigation
var engineShutOffTime-
(float) Filled in by
TabulatedMotorupon initialization var environment-
Instance of
Environment var eventTimeStep-
If using an adaptive time stepping method, the time step will be overridden near non-time-deterministic discrete events, possibly all the way down to this minimum value
var finenessRatio-
Used in some aerodynamic functions. Updated after initializing subcomponents, and throughout the flight. None if no BodyComponent(s) are present in the rocket
var fullyTurbulentBL-
Controls whether skin friction is solved assuming a fully turbulent BL or using laminar/transitional flow at lower Reynolds numbers
var isUnderChute-
(bool) Controlled by
RecoverySystem._deployNextStage() var mainChuteDeployTime-
(float) Filled in during flight by
RecoverySystem._deployNextStage() var maxDiameter-
(float) Holds maximum constant-size body tube diameter, from bodytube components in stages
var recoverySystem-
Reference to the current Rocket's (which can represent a dropped stage) recovery system. Only a single recovery system is allowed per stage.
Set inRecoverySystem var rigidBody-
(
RigidBodyorRigidBody_3DoF) Responsible for motion integration.
Set in_initializeRigidBody(). var silent-
Controls output to console
var simEventDetector-
(
SimEventDetector) Used to trigger things like recovery systems and staging var simRunner-
Parent instance of
Simulation(or derivative sim runner). This is usually the object that has created the current instance of Rocket. var stage-
If controls whether the whole rocket is initialized (if == None), or a single stage is initialized (Integer stage number)
var stages-
A list of
Stageobjects that make up the rocket, ordered from top to bottom.
Populated by_initializeStages. var surfaceRoughness-
Default surface roughness for all rocket components
var timeStepLog-
Log containing one entry per time step, logs rocket state. None if logging level == 0
var turbulenceOffWhenUnderChute-
(bool)
Methods
def getLength(self)-
Expand source code
def getLength(self): totalLength = 0 for stage in self.stages: try: totalLength += stage.getLength() except TypeError: pass # Stage Length was None - no body components in stage return totalLength def plotShape(self)-
Expand source code
def plotShape(self): plt.figure() plt.gca().set_aspect('equal') rocketInertia = self.getInertia(0, self.rigidBody.state) TotalCG = rocketInertia.CG.Z TotalMass = rocketInertia.mass TotalCGplt = plt.plot(TotalCG, 0, color='b', marker='d', label='Total CG', linestyle='None') CGsubZ = [] CGsubY = [] plt.title('Total Rocket CG: %10.4f m \n Total Rocket Mass: %10.4f Kg' % (TotalCG,TotalMass) ) for stage in self.stages: zCGs, yCGs = stage.plotShape() # Add subcomponents CGs to arrays CGsubZ += zCGs CGsubY += yCGs SubCGplt = plt.plot(CGsubZ, CGsubY, color='g', marker='.', label='Subcomponent CG', linestyle='None') legendHeight = self.maxDiameter plt.legend(loc='upper center', bbox_to_anchor = (0.5,-1.05)) plt.show() def timeStep(self, dt: float)-
Tells the simulation to take a time step of size dt.
Usually called by functions like
Simulation.run()Returns
- timeStepAdaptationFactor: (float) indicates the factor by which the adaptive time stepping method would like to change the timestep for the next timestep (1.0 for non-adaptive methods)
- dt: (float) actual size of time step taken. Adaptive methods will override the dt asked for if the predicted error for a time step is over their error threshold.
Expand source code
def timeStep(self, dt: float): ''' Tells the simulation to take a time step of size dt. Usually called by functions like `MAPLEAF.SimulationRunners.Simulation.run()` Returns: * timeStepAdaptationFactor: (float) indicates the factor by which the adaptive time stepping method would like to change the timestep for the next timestep (1.0 for non-adaptive methods) * dt: (float) actual size of time step taken. Adaptive methods will override the dt asked for if the predicted error for a time step is over their error threshold. ''' # Stop the rocket from sliding off the bottom of the launch rail self.rigidBody.state = self.environment.applyLaunchRailMotionConstraints(self.rigidBody.state, self.rigidBody.time) # Trigger any events that occurred during the last time step estimatedTimeToNextEvent, accuratePrediction = self.simEventDetector.triggerEvents() # If required, override time step to accurately resolve upcoming discrete events if "Adapt" in self.rigidBody.integrate.method and estimatedTimeToNextEvent < dt: if accuratePrediction: # For time-deterministic events, just set the time step to ever so slightly past the event newDt = estimatedTimeToNextEvent + 1e-5 print("Rocket + SimEventDetector overriding time step from {} to {} to accurately trigger resolve time-deterministic event.".format(dt, newDt)) dt = newDt else: # For time-nondeterministic events, slowly approach the event newDt = max(estimatedTimeToNextEvent/1.5, self.eventTimeStep) estimatedOccurenceTime = self.rigidBody.time + estimatedTimeToNextEvent print("Rocket + SimEventDetector overriding time step from {} to {} to accurately resolve upcoming event. Estimated occurence at: {}".format(dt, newDt, estimatedOccurenceTime)) dt = newDt self._runControlSystem() self._logState() # Take timestep integrationResult = self.rigidBody.timeStep(dt) # If required, log estimated integration error if "Adapt" in self.rigidBody.integrate.method and self.timeStepLog is not None: self.timeStepLog.logValue("EstimatedIntegrationError", integrationResult.errorMagEstimate) return integrationResult def writeLogsToFile(self, directory='.')-
Expand source code
def writeLogsToFile(self, directory="."): logfilePaths = [] if self.timeStepLog is not None: rocketName = self.components[0].name # Rocket is named after its top stage path = os.path.join(directory, "{}_timeStepLog.csv".format(rocketName)) # Time step log if self.timeStepLog.writeToCSV(path): logfilePaths.append(path) # Derivative evaluation log if self.derivativeEvaluationLog is not None: path = os.path.join(directory, "{}_derivativeEvaluationLog.csv".format(rocketName)) if self.derivativeEvaluationLog.writeToCSV(path): logfilePaths.append(path) # Calculate aerodynamic coefficients if desired if self.loggingLevel > 2: expandedLogPath = Logging.postProcessForceEvalLog(path, refArea=self.Aref, refLength=self.maxDiameter) logfilePaths.append(expandedLogPath) # Control system log if self.controlSystem != None: if self.controlSystem.log != None: controlSystemLogPath = self.controlSystem.writeLogsToFile(directory) logfilePaths.append(controlSystemLogPath) return logfilePaths
Inherited members
- rocketDictReader:
(
